Applicable scope：

◆ Suitable for 100% automatic detection of printing quality of roll printing base materials, such as adhesive labels, transparent/semi-transparent materials and films in pharmaceutical, food, daily chemical, electronic, anti-counterfeiting and other industries.

◆ Suitable for 100% automatic detection of printing quality of web lower than 80g/m2.

Product features：

◆ Servo drive, PLC control, max. speed up to 200m/min, stable operation and simple operation;

◆ The standard configuration includes double correction device, double winding device, slitting device and closed-loop tension control. It can meet the requirements for production with high performance;

◆ High-speed detection: max. detection speed up to 200m/min, high production efficiency;

◆ Error-based stop function: quick stop plan; compared with traditional slow stop, the stop speed isincreased by 20%; the stop accuracy is up to ±2cm;

◆ Support non-stop detection. After detection, remove the defects on the rechecking machine to improve production efficiency.

Video introduction：

            Cigarette label rewinding inspection machine

                           Self-adhesive rewinding tester
